Multi Spectral Imagery

Substar point ground pixel resolution

Visible light near infrared:5m;

Shortwave/Mediumwave infrared camera:100m;

Longwave infrared camera:150m

Spectral bands

B0:450nm-800nm        B1:403nm-423nm
B2:433nm-453nm        B3:450nm-515nm
B4:525nm-600nm        B5:630nm-680nm
B6:784.5nm-899.5nm     B7:485nm-495nm
B8:615nm-625nm        B9:650nm-680nm
B10:698.75nm-718.75nm  B11:732.5nm-747.5nm
B12:773nm-793nm       B13:855nm-875nm
B14:660nm-670nm       B15:677.5nm-685nm
B16:750nm-757.5nm      B17:758.75nm-762.75nm
B18:935nm-955nm       B19:1000nm-1040nm
SW1:1195nm-1225nm    SW2:1360nm-1390nm
SW3:1550nm-1590nm    SW4:1610nm-1690nm
MW:3700nm-4950nm     LW:7500nm~13500nm

Standard scene size (at nadir)

Visible light near infrared:58.7km×58.7km
Shortwave/Mediumwave infrared camera:64km×64km
Longwave infrared camera: 96km×96km

Positioning accuracy

50m (CE90)

Photographic mode

Push-broom

Photographic satellite

GP01; GP02
