JL1 satellites can not only capture the images of the earth, but they can also turn the cameras to photograph space objects, such as the space station, the moon and other objects near the earth.
It can be used for astronomical target observation.
Short-range artificial target observation.
Indicators | Parameter |
Angular resolution | 0.35 angular sec |
Standard duration | 10s; 30s; 60s |
Maximum duration | 120s |
Frame rate | SP03-08:1/2/5/10 frame /s GF03C:1/2/5 frame /s (minimum 0.1, freely set) |
Standard field of view size | SP03-08:1.1×0.5° for Single camera (SP04~08 is spliced by double cameras, and it is about 2.1×0.5°) GF03C series:1.5×0.6° |
Video image stabilization accuracy | ≤0.5 pixel |
Maximum angular velocity of maneuvering imaging | ≥ 1°/s |
Highest recognized magnitude | SP03-08:12 magnitude GF03C series:10 magnitude |
Shooting satellite | SP03-08; GF03C series |
Massive imagery data in both daily archived or task programming is changing the way you see the world.
